International Microwave Symposium
International Microwave Symposium 2016, Moscone Center SF

Come by our booth and see the latest is RF probe and connector technologies to 70GHz

IMS 2016 Visit Booth 2541 listed as Signal Microwave.

 if you are a Signal Integrity Engineer that wants a demonstration of a 40GHz probing system for measuring differential impedance and S-parameters to verify SPICE models or Manufacturing quality of PCB Prototypes.

At the booth learn how to use the latest 40 GHz 4port VNA/TDR from Anritsu connected to the DVT40 GigaProbes utilizing a new low cost desktop probing system to extract differential Impedance and S-parameters on a new probing demonstration board. Find out which VNA/TDR or probing system configuration is right for you…

Our partner Signal Microwave will be introducing new solder-less RF connectors from 40 to 67GHz.  The 40GHz/2.92mm interface connectors are available in both vertical and edge mount geometries with the 67 GHz/1.85mm interface connectors supporting PCB edge mount applications. These solder-less edge mount connectors provide superior signal integrity performance. New Connectors will include 1.85 70GHz through adapters and new low cost 2.92 Field Replacable Connectors.

Engineers will be available to discuss how to optimize the coaxial-to-PCB performance transitions by providing free 3D connector to PCB electrical launch models, customer specific PCB footprints to assure measurement repeatability and electrical transparency. FREE DEMO connector’s samples are available while they last.

Call 650 593-7083 or email: sales@gigaprobes.com  for a personal demo.

Vendor demonstraion days and hours:

Tuesday, 24 May 0900 to 1700
Wednesday, 25 May
Industry Hosted Reception

0900 to 1700
1700 to 1800

Thursday, 26 May 0900 to 1500




Image:
NEW Low Cost Solder-less 40-67GHz Vertical and Edge Mount Connectors
40GHz vertical launch connectors
40Ghz Solder-Less Vertical launch connectors
Click on the "RF Connectors" Tab on the left side of the page for more information on the new 40GHz solder-less Edge Mount and Vertical Mount Connectors.  Get a free connector sample!Sealed

40Ghz Edge mount connectors, 67GHz edge mount connectors
40GHZ and comming 67GHz edge mount connectors
NEW DVT40-1MM 40 GHz TDR/VNA S-parameter Probe kit

 DVT40 GigaProbes 40 GHz TDR/ VNA S-parameter probe is a 40 GHz multi-impedance mode hand probe functions as a 50 or 100 ohm odd mode differential probe with ~3.5ps TDR rise time loss. To probe with a VNA, the differential 40GHz 2.92mm K connectors with dual conductor strip line incorporates a configurable ground collar. The two signal pins are 50 ohms referenced to a user configurable ground pin that form up to ten different ground/signal patterns. Measured S-parameters are provided in S2p or S4p file format to de embed the probe from the measurement. Design Verification Engineers use the DVT40 probe to verify differential impedance or S-parameter frequency performance of PCB designs using Time Domain or Vector Network Analyzer instruments from Keysight, Rohde & Schwarz, LeCroy, Agilent and a Tektronix.


40Ghz TDR probe, 40Ghz VNA probe, DVT40-1MM VNA Measurements, GigaProbes
DVT40-1MM 40GHz TDR/ VNA S-parameter Probe Kit


Document
DVT40-1MM TDR/VNA S-prameters probe kit
DVT30-1MM and DVT30-1MM-1 Dual and Single 100Ohm Differential/50Ohm TDR Probe Kits
DVT30-1MM Gigaprobes TDR and TDT Analysis
DVT30-1MM GigaProbes™ Complete TDR/TDT Interconnect Analysis Kit.
GigaProbes Accessory Kit
DVT30-1MM-1 GigaProbes(r) Accessory Kit containing one GigaProbes that can be converted to 100 or 50 ohm probe. Kit contains same accessories as the DVT30-1mm kit
Image:
The DVT30-1MM GigaProbes® contains two 30Ghz balanced odd mode 100 ohm differential Time-Domain Reflectometry (TDR) probes featuring Gold Plated Conductive Diamond probe tips. Accessories are included to convert the probes to 50 ohm single-ended. DVT30-1MM comes with a set of ergonometric grips for comfortable hand probing and accessories are included to attach the probes to the Probe Articulating Arms and Probe Stations. This 30GHz TDR probe measures ODD mode impedance profiles and can be used with the LeCroy, Tektronix, Agilent,  Hyper Labs or any legacy TDR oscilloscopes. With a typical differential launch discontinuity of 20mv and a fall-time of less than 30ps, these probes mask only 20 mils of the device under test. This small discontinuity mask becomes significant when characterizing IC packages where net lengths are very short. The Signal-to-Signal pitch can be set to 0.4 to 1.8 mm using the special SMA Pitch Setting Wrench or customized using other tools supplied in the DVT30-1MM GigaProbes® accessory kit


TDR and Test Equipment Compatibility
The DVT30 Gigaprobes™ are compatible with  all 20Ghz Agilent, Tektronix, and LeCroy TDR Systems, TDR modules and as a Probe for injecting and measuring digital patterns for the SyntheSys Research BERTScope.



Two GigaProbes Interconnect Kits are Now Available!



GigaProbes® Now come in a one probe and two probe configuration. The DVT30-1MM has two 50/100 ohm probes to address the need for full PCB analysis where TDR/TDT measurements and insertion/return loss S-parameters are extracted to determine interconnect bandwidth performance. The NEW DVT30-1MM-1 contains one probe for 50 or 100 ohm impedance measurements or for PCB Failure Analysis testing. Each kit comes with cables and accessories for adjusting the probe pitch.




DVT30-1MM GigaProbes® dual probe kit comes with a full set of accessories for a complete TDR/TDT interconnect analysis.
Each GigaProbes® TDR/TDT Kit includes:

1.
Two 30GHz 100 ohm differential TDR probes
2.
Two - Easy-grip sleeves
3.
SMA wrench with 0.8, 1.0, 1.27 mm probe tip pitch calibration holes
4.   5x Free Standing
Microscope
5.
110 mm tweezers for fine pitch setting of probe tips
6.
Four right angle connectors
7.
50 Ohm single ended conversion kit to include 2 SMA shorting caps and grounding strap
8.   Four cables with t
wo cable wraps for easy cable management
9.   Micro Manipulator Adapter for the Tektronix PPM100 and PPM203 probe manipulators

10.
Signal integrity resource disk and binder includes application notes and data sheets
11. Free W
eb site support, IConnect Video Download Seminar, LeCroy TDR and S-parameter Seminar, Application notes


GigaProbes Diamond Plated Probes
Gold Plated Probe Body and Diamond Plated Probe Tips

" NEW "

Gold-Plated Probe with Conductive Diamond Probe Tips
Patent Pending


  • Gold Plated Probe Body Improves 50 ohm conversion
  • Probe Tips Never Oxidize
  • Easily Breaks Through Surface Oxide When Probing
  • Creates A Probe Connection As Good As Solder
  • Repeatable High Bandwidth TDR Measurements
  • Allows Probing At Any Angle
  • Conductive Diamond Plating Technology by Giga Connections, Inc.

For more information on Gold Plated Conductive Diamond Technology
Visit
Web Site: (www.gigaconnections.com)




TDR probe
Clos-up of Diamond Probe Tip
TDR Probe
Diamonds allow for probing at any angle
Document
Description of Gold Plated Conductive Diamond Platng

Features & Benefits

  • 30 GHz
  • True Odd Mode 100 Ohm Differential Input Impedance
  • Adaptable to 50 Ohm Single Ended Input Impedance
  • Adjustable Probe Pitch From 0 to 2mm
  • 10 Mil Diameter Probe Tips
  • Fall Time <30ps, or="" 5ps="" fall="" time="" degradation="" strong="">
  • Differential Launch Discontinuity <20mv
  • Universal Probe Design, Use as Hand Probe or Mount in Micro-positioners
  • Full Set of Probe Pitch Calibration Accessories
  • Fully Balanced Differential Signals without Ground Contact
  • Variable Pitch


Characteristics

  • Attenuation – 1X
  • Probe Only Bandwidth – 30 GHz.
  • TDR Degradation – <5ps
  • Probe Pitch – .25 mm to 2 mm (signal tip to signal tip)
  • Connector Type – SMA
  • Measured Reflected TDR Fall Time – <22 ps.
  • Impedance – 100 ohm Differential, 50 Ohm Common Mode,
  • 50 Ohm Single Ended
  • Max Vin – 5.0 V
  • (Note: numeric values shown are typical).

Media
Short Video showing GigaProbe Performance test using 9ps 50 GHz Differential TDR System
